Product Description
It is one of the necessary equipment for fertilizer, chemical, food, electronics and other industrial sectors to process granular raw materials into capsule tablets or granules. It is suitable for batch production, laboratories, hospitals and other sectors to press tablets, sugar tablets, calcium tablets, coffee tablets and various pesticide and fertilizer tablets with stick tablets. It can press various special-shaped and ring-shaped tablets, and can press tablets with trademarks, texts and simple graphics engraved on both sides.
Technical Data
|
Model |
SFTPH-10 |
SFTPH-20 |
SFTPH-30 |
|
Working pressure |
10t |
20t |
30t |
|
Maximum stroke of upper punch |
100mm |
100mm |
110mm |
|
Loading height |
40mm |
40mm |
80mm |
|
Maximum die diameter |
40mm |
40mm |
80mm |
|
Production times per minute |
25 |
25 |
20 |
|
Product Error |
±0.05 |
±0.05 |
±0.05 |
|
Power |
3kw |
4kw |
4kw |
Note: the parameters above only for reference, will revise accordingly from different materials and projects
